Western Windows Product Knowledge Presentation
Sizing Options
60mm Housing Singles Standard Mesh: 6'(W) x 11'(H)
60mm Housing Doubles Standard Mesh: 12'(W) x 11'(H)
70mm Housing Singles Standard Mesh: 9’(W) x 11'(H)
70mm Housing Doubles Standard Mesh: 18'(W) x 11’(H)
80mm Housing Singles Standard Mesh: 14’(W) x 11’(H)
80mm Housing Doubles Standard Mesh: 28’ (W) x 11’(H)
Finish Options
Mesh Options
Phifer Patio Mesh 18 x 14 (58% Openness)
Designed for applications where extra strength is desired. Ideal for large openings.Phifer Tuff Screen 17 x 13 (45% Openness 55% UV)
Heavy-duty, vinyl-coated polyester insect screening that is ideal for use in high traffic areas. Pet resistant and tear and puncture resistant. Tuff Screen is stronger than regular insect screening. Treated with Microban to prevent the growth of bacteria.Twitchell Super Mesh Screen 17 x 20 (55% Openness)
Over the years Super Screen has provided innovative technology for multiple applications. SuperScreen offers superior performance characteristics and is covered by Twitchell's ten-year limited warranty. SuperScreen is a vinyl coated - polyester.Western Windows Systems Installation Instructions
Image References
600 Series 3600 SeriesTechnical Resources
- Installation Video YOUTUBE
- 60mm Component View .pdf
- 70mm Component View .pdf
- 70mm Door View .pdf
- 80mm Component View .pdf
- 80mm Door View .pdf
- Corner Application View .pdf
- Split Level Application .pdf
- VistaView 60DWG .dwg
- VistaView 70 DWG .dwg
- VistaView 80DWG .dwg
